HV Cable 3C 3Prong 16.5mm Diameter Cable 14'8 Long

2172008
X-Ray
GE Healthcare
Outright
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Flexible multi-conductor high voltage cable
  • Easy to connect and terminate
  • Low noise
  • Very good conductivity

Product Overview

The low noise 3 Conductor HV Cable Assembly is a custom designed part, suitable for use in medical diagnostic imaging equipment, X-ray equipment and other medical applications as applicable. The cable is used to provide the anode and cathode voltages to the X-ray tube. The cable assembly has 4.47 m long 3 conductor 15AWG tinned copper high voltage cable, with light weight connector and retainer rings at both ends of the cable. The cable insulation is made up of high quality Ethylene Propylene Rubber (EPR) material, having excellent dielectric strength and chemical resistance property, which makes it well suited for demanding applications. The cable offers excellent resistance to mineral oils, synthetic oils and chemicals.

Compatible Products

Definium AMX700

Definium AMX700
